ABB AI830 3BSE008518R1 S800 I/O Systems Analog Input Module

ABB AI830 3BSE008518R1 S800 I/O Systems Analog Input Module

Manufacturer:ABB

Product Number:AI830 3BSE008518R1

Product Type:Analog Input Module

Origin:Sweden (SE)

Dimensions:45 x 102 x 119 mm

Weight:0.22 kg

Views:28

Payment Methods:T/T, PayPal, Western Union

Condition:New & In Stock

Shipping Port:Xiamen, China

Warranty:1 Year

Lead Time:1-3 Working Days

Certificate:COO

Courier partners:DHL, UPS, TNT, FedEx and EMS.

Business hours:7*24

Send Inquiry
Description
FAQ
Products Description
https://www.tilgames.com/wp-content/uploads/2025/03/3-7.jpg
https://www.tilgames.com/wp-content/uploads/2025/03/4-9.jpg
https://www.tilgames.com/wp-content/uploads/2025/03/5-9.jpg
https://www.tilgames.com/wp-content/uploads/2025/03/2-10.jpg
Company Information
E-mail [email protected]
Mobile +8613666033393
Whatsapp +8613666033393
WeChat 13666033393
Add Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Introduction

The ABB AI830 3BSE008518R1 is an 8-channel RTD input module designed for use in S800 I/O Systems. It provides precise temperature measurement using resistive temperature detectors (RTDs) and resistive sensors. This module supports 3-wire RTD connections, ensuring accurate and stable measurements by compensating for lead wire resistance.

The AI830 is compatible with Pt100, Cu10, Ni100, and Ni120 sensors and performs automatic linearization and temperature conversion into Centigrade or Fahrenheit. It incorporates built-in diagnostics to detect open circuits, short circuits, and grounded sensors.

Designed for industrial automation and process control, the AI830 3BSE008518R1 offers high-resolution 14-bit data processing, advanced filtering options, and support for 50 Hz or 60 Hz mains frequency settings to minimize electrical interference.
